(POE40++) 4 Port IP Signal & Power PoE Extender

This unit regenerates the data and power for (4) IP PoE cameras. The maximum wire distance from the camera to the unit is 300 feet using Cat6 (for each camera) .

• - No. OF POE Ports: 4
• - Pass Through Data Rates: 10/100 Mbps
• - Switch Type: External
• - Standard: •IEEE 802.3: 10 BASE-T, •IEEE 802.3u: 100 BASE-TX, •IEEE 802.3af: Power Over Ethernet
• - POE Spec: •Supports up to 15.4 W for each PoE port, •PoE over current protection
• - MAC Address Table: 1K
• - Buffer Memory: 512K bits
• - Transmission Method: Store and Forward
• - Output Power Voltage: 52 VDC Maximum
• - User Port Power: 30 Watts Per Channel
• - Input Power NONE REQUIRED
• - Dimensions: 1.1" x 3.54" x 4.72" (28mm x 90 mm x 120 mm)
• - Weight: 12.25 Oz(350g)
• - Connectors: RJ-45
• - Operating Ambient Temperature: 14ºF to 113 ºF (-10℃ to 45 ℃)
• - Regulatory: IEEE 802.3ax, RoHS Compliant, CE/FCC
• - UL Listed
